​220-260 GHz Down Converters for 5G/6G Applications

Experience unparalleled performance with our full band coverage solutions, meticulously designed to deliver compact, low-loss performance. Setting an industry benchmark, our offerings boast the lowest insertion loss, ensuring optimal signal integrity for your applications. Benefit from exceptional VSWR (Voltage Standing Wave Ratio) and high isolation capabilities, providing reliability and efficiency. Our cutting-edge technology extends the coverage up to an impressive 400 GHz, offering a comprehensive solution for diverse frequency requirements. Elevate your communication and signal processing needs with our top-tier, high-frequency solutions tailored for maximum performance and minimal signal loss.

Low Loss Waveguide Isolators for 50-400 GHz
Outline drawing for waveguide isolators
  • Full band coverage

  • Compact, low loss

  • Lowest insertion loss in industry

  • Low VSWR

  • High isolation

  • Available up to 400 GHz

Specifications

Model
Frequency (GHz)
Insertion Loss (dB); typical, max
Isolation (dB); typical
Waveguide, Flange
THZISO-VFB
50 – 75
1.3
> 20
WR 15, UG 385/U
THZISO-WFB
75 – 110
1.3
> 20
WR 10, UG387/U-M
THZISO-FFB
90 – 140
1.5
> 20
WR 08, UG 387/U-M
THZISO-DFB
110 – 170
0.8, 1.3 max
> 20
WR 06, UG 387/U-M
THZISO-GFB
140 – 220
1.7 typical, 2.3 max
> 20
WR 05, UG 387/U-M
THZISO-43FB
170 – 260
1.7 typical, 3.2 max
> 22
WR4.3, UG 387/U-M
THZISO-YFB
220 - 330
2.3 typical, 3.5 max
> 25
WR 3.4, UG 387/U-M
THZISO-28FB
260 - 400
3.8 typical, 5.6 max
> 25
WR 2.8, UG 387/U-M

1. How to make a request: Select a model above, or provide required frequency range, insertion loss, isolation, and waveguide size, send email to: sales@vivatechthz.com
2. These compact isolators offer lower loss than conventional designs
3. How to make a request: specify Model number. Email to: sales@vivatechthz.com

220-330 GHz Low Loss Isolator Performance
